  • Performance
  • Specifications
  • Manual
Features:
Continuous-duty, thermally protected split capacitor motor
Stainless steel with cast iron base and thermoplastic handle
2 in. FIP discharge
2 in. MIP x 1-1/2 in. FIP threaded adapter included
Thermoplastic vortex impeller
Vertical float switch
Sku / Model 691-3210 / BA92751
HP 3/4
Amps 7.5
Pump Construction Stainless Steel / Cast Iron
Discharge Size 2 in. (1-1/2 in. NPT adapter included)
Discharge Type Side
Impeller Type Thermoplastic Vortex Impeller
Cord Length 10'
Solids Handling 1/2"
Switch Type Vertical Float Switch
UL Listed Yes
Dimensions 9-1/2 in. L x 9 in. W x 14-1/4 in. H
Warrany Lifetime Warranty
