  • Performance
  • Specifications
  • Manual
Sump Kit Features:
Powerfull 1/2 hp sump pump with the added security of a battery operated backup system
Pre-assembled kit easily connects to new or existing discharge line
For use in sump applications with basins 18 in. wide or larger
Primary Pump Features:
1/2 hp 120 volt 7.6 amp AC motor
Tough cast iron construction
1-1/2 in. FIP discharge
Thermoplastic impeller
Vertical float switch
Pumps up to 1/2 in. solids
Backup Pump Features:
12 Volt dc motor
Tough thermoplastic construction
1-1/4 in. MIP or 1-1/2 in. MIP discharge
Thermoplastic impeller
Vertical float switch
Pumps up to 1/8 in. solids
Additional Features:
Electronics control panel with indicator lights
87 decibel alarm with mute
Thermoplastic battery box
Battery terminals included
Low battery alarm
Pre-assembled with PVC piping and two full flow check valves
AC charger with power cord
12 volt deep cycle battery sold separately
Sku / Model 691-3222 / BA92911
Primary HP 1/2
Backup HP 12 volt
Primary Amps 7.6
Backup Volts 12 volt
Primary Construction Cast Iron
Backup Construciton Thermoplastic
Primary Discharge Size 1-1/2 in.
Backup Discharge Size 1-1/4 in. or 1-1/2 in.
Primary Discharge Type Side
Backup Discharge Type Top
Primary Cord Length 10 ft.
Backup Cord Length 10 ft.
Primary UL Listed Yes
Backup UL Listed Not Required
Primary Switch Type Vertical Float Switch
Backup Switch Type Vertical Float Switch
Primary Solids Handling 1/2 in.
Backup Solids Handling 1/8 in.
Primary Impeller Thermoplastic
Backup Impeller Thermoplastic
Sump Kit Dimensions 10-1/2 in. x 10 in. x 20-1/2 in.
Battery box internal dimensions 13-1/8 in. L x 7 in. W x 8.5 in. H
Warranty 5 year
